Equipment
Every machine on the floor, grouped by process. Select "View Full Specs" on any card to expand the complete technical specification table.
Swiss-Style / Multi-Axis Turning
1 Machine
Ganesh Cyclone 32-CS
Complete complex small-part machining in a single setup. Simultaneous milling and turning from 0.25" to 1.375" diameter, guidebush-less design, with a 12' Edge Patriot bar feeder for lights-out production.
| Machine Type | 7-Axis Sliding Headstock CNC Swiss Lathe (guidebush-less) |
|---|---|
| Max Bar Diameter | 1.375" (36 mm) |
| Max Machining Length | 6" |
| Main Spindle Motor | 10 HP |
| Main Spindle Speed | Up to 6,000 RPM |
| Sub-Spindle Motor | 5 HP continuous / 7.5 HP peak |
| Sub-Spindle Speed | Up to 6,000 RPM |
| Sub-Spindle Bar Capacity | 1.25" |
| X-Axis Travel | 7.28" |
| Y-Axis Travel | 19.29" |
| Z-Axis Travel | 6.50" |
| C-Axis Resolution | 0.001° |
| Minimum Input Unit | 0.00005" (50 millionths) |
| Rapid Traverse Speed | 1,180 IPM |
| OD Turning Tools | 6 positions (1/2" or 12 mm) |
| ID Turning Tools | 5 positions (25 mm bore) |
| Cross Slide Live Tools | 4 stations |
| Front Slide Live Tools | 3 stations |
| Live Tool Collet | ER-20, 1/2" (13 mm) shank |
| Live Tool Max RPM | 4,000 RPM |
| Bar Feeder | 12' Edge Patriot |
| Machine Weight | ~8,400 lbs |
CNC Lathes: Milling and Turning Centers
4 Machines
Doosan Puma 2100SY II
Done-in-one machining with sub-spindle, Y-axis, and live tooling. Eliminates secondary operations on complex turned parts. 8" main chuck and 6" sub-spindle with FANUC touchscreen control.
| Machine Type | Multi-Axis CNC Turning Center with Sub-Spindle, Y-Axis, and Live Tooling |
|---|---|
| Max Turning Diameter | 16" |
| Max Turning Length | 20.5" |
| Main Spindle Chuck | 8" |
| Main Spindle Speed | Up to 5,000 RPM |
| Main Spindle Power | 22 kW (30 HP) |
| Sub-Spindle Chuck | 6" |
| Sub-Spindle Speed | Up to 6,000 RPM |
| Sub-Spindle Power | 15 kW (20 HP) |
| Bar Capacity | 2.6" |
| Max Swing Over Bed | 30.7" |
| X-Axis Travel | 10.2" |
| Z-Axis Travel | 23.2" |
| C-Axis Resolution | 0.001° (both spindles) |
| Live Tool Speed | Up to 5,000 RPM |
| Live Tool Motor | 7.5 HP |
| Turret | 12-station live milling capable |
| Rapid Traverse | 1,181 IPM (30 m/min) |
| CNC Control | FANUC 0i-Plus with iHMi touchscreen |
| Bar Feeder | 4' bar feeder |
Doosan Lynx 220LM
Small to mid-size precision turning with live tooling and C-axis for cross-hole drilling and off-center milling. Reduces cycle time on combination parts with a 3' bar feeder for automated runs.
| Machine Type | CNC Turning Center with Live Tooling and C-Axis |
|---|---|
| Max Turning Diameter | 9.8" |
| Max Turning Length | 20.1" |
| Chuck Size | 6" |
| Bar Capacity | 2" |
| Swing Over Bed | 20.1" (510 mm) |
| Swing Over Cross Slide | 11.4" (290 mm) |
| Main Spindle Speed | Up to 6,000 RPM |
| Main Spindle Motor | 20 HP (12 kW) |
| Spindle Bore | 53 mm |
| Spindle Taper | ASA A2-5 |
| X-Axis Travel | 6.9" (175 mm) |
| Z-Axis Travel | 21.7" (550 mm) |
| C-Axis | Yes, for milling and cross-hole drilling |
| Live Tool Motor | 5 HP |
| Turret | 12-station |
| OD Tool Size | 0.8" × 0.8" |
| CNC Control | FANUC 0i-TC |
| Bar Feeder | 3' bar feeder |
| Machine Weight | ~8,800 lbs (4,000 kg) |
Daewoo Puma 240
High-torque turning of larger diameter stock up to 13.8" with a 10" chuck, 25 HP spindle motor, and 3.03" bar capacity. Built for production turning of shafts, bushings, housings, and similar components.
| Machine Type | 2-Axis CNC Turning Center |
|---|---|
| Max Turning Diameter | 13.8" |
| Max Turning Length | 21.1" |
| Max Swing Over Bed | 21.7" |
| Chuck Size | 10" 3-jaw hydraulic |
| Bar Capacity | 3.03" |
| Spindle Bore | 3.54" |
| Spindle Speed Range | 35–3,500 RPM |
| Spindle Motor | 25 HP |
| Spindle Nose | A2-8 |
| X-Axis Travel | 9.52" |
| Z-Axis Travel | 17.3" |
| Distance Between Centers | 22" |
| Turret Stations | 10-position |
| CNC Control | FANUC 21i-TB |
| Additional Equipment | Tailstock, chip conveyor |
Daewoo Lynx 210
High-precision compact turning with a 6" chuck and FANUC control. Well suited for automotive, aerospace, and medical components in small to medium production runs requiring tight tolerances.
| Machine Type | Compact 2-Axis CNC Turning Center |
|---|---|
| Max Turning Diameter | 11" |
| Max Turning Length | 11.8" |
| Max Swing | 18" |
| Chuck Size | 6" |
| Bar Capacity | 1.75" |
| Spindle Motor | 10 HP |
| X-Axis Travel | 6.3" |
| Z-Axis Travel | 13" |
| Turret | 12-station |
| CNC Control | FANUC 21i-T |
| Optional Features | Tool presetter, parts catcher |
Manual / Toolroom Lathes
2 Machines
Southwestern TRL 1630SX
Flat bed CNC lathe with conversational ProtoTRAK SLX control for fast programming at the machine without G-code. Ideal for prototype, one-off, and short-run work that demands precision and quick turnaround.
| Machine Type | Flat Bed CNC Toolroom Lathe |
|---|---|
| Swing Over Bed | 16" |
| Max Machining Length | 30" |
| Chuck Size | 8" |
| Bar Capacity | 2" |
| Spindle Through Hole | 2.12" |
| Spindle Speed Range | 150–2,500 RPM |
| Spindle Motor | 7.5 HP |
| Spindle Nose | D1-6 Camlock |
| Spindle Taper | MT-6 |
| Cross Slide Travel | 8.5" |
| CNC Control | ProtoTRAK SLX |
| Drive System | Brushless servo motors, inverter-duty spindle drive |
| Input Devices | Electronic handwheels and jogstick |
| Machine Dimensions | 87"L × 45"W × 67"H |
| Machine Weight | 2,750 lbs |
Clausing 13" Lathe
Manual geared head gap bed engine lathe with 16 speed positions from 33 to 2,000 RPM. Built for light-duty turning, tool making, and quick secondary operations that don't require CNC programming.
| Machine Type | Manual Geared Head Gap Bed Engine Lathe |
|---|---|
| Swing Over Bed | 13" |
| Swing Over Cross Slide | 7.5" |
| Spindle Speed Range | 33–2,000 RPM (16 speeds) |
| Spindle Motor | 3 HP |
| Spindle Bore | 1.37" |
| Spindle Nose | D1-4 Camlock |
| Tailstock Quill Diameter | 1.56" |
| Tailstock Taper | MT-3 |
| Threading | Inch and metric capability |
| Power | 3-Phase, 230/460V |
CNC Vertical Machining Centers
3 Machines
Doosan DNM 4500
Medium-size prismatic part machining with BigPlus dual-contact CAT 40 spindle, 30-tool magazine, through-spindle coolant, and FANUC control. Handles complex multi-operation jobs with minimal manual intervention.
| Machine Type | 3-Axis CNC Vertical Machining Center |
|---|---|
| X-Axis Travel | 31.5" (800 mm) |
| Y-Axis Travel | 17.7" (450 mm) |
| Z-Axis Travel | 20.1" (510 mm) |
| Spindle Speed | Up to 8,000 RPM (15,000 RPM on S variant) |
| Spindle Power | 20 HP |
| Spindle Type | BIGPLUS (dual-contact) |
| Tool Taper | CAT 40 |
| Tool Magazine | 30 tools (expandable to 40 or 60) |
| Max Table Load | 1,320 lbs (600 kg) |
| CNC Control | FANUC 0i-M with DN Solutions EOP |
| Coolant Tank | 325 liters |
| Standard Features | Through-spindle coolant, spindle chiller, dual chip augers |
| Machine Dimensions | 90.6"L × 105.9"W × 103.7"H |
Doosan DNM 400 II
General purpose precision milling with 30-tool ATC, CAT 40 spindle, and FANUC 0i-M control. Similar capability to the DNM 4500 in a slightly smaller envelope, ideal for fixtures, brackets, housings, and plates.
| Machine Type | 3-Axis CNC Vertical Machining Center |
|---|---|
| X-Axis Travel | 30.0" (762 mm) |
| Y-Axis Travel | 17.1" (435 mm) |
| Z-Axis Travel | 20.1" (510 mm) |
| Spindle Speed | Up to 8,000 RPM |
| Spindle Power | 20 HP (15 kW) |
| Max Spindle Torque | 86 ft-lb (117 Nm) |
| Tool Taper | CAT 40 |
| Tool Magazine | 30 tools |
| Table Size | 36.2" × 17.1" (920 × 435 mm) |
| Max Table Load | 1,320 lbs (600 kg) |
| Spindle Nose to Table | 5.9"–26.0" |
| Coolant Tank | 300 liters |
| CNC Control | FANUC 0i-M |
| Machine Weight | ~12,125 lbs (5,500 kg) |
| Machine Dimensions | 85.6"L × 103.0"W × 106.7"H |
Excel PMC5T18
Compact precision milling with 18-tool side-mount ATC and CAT 40 spindle. Handles drilling, tapping, and contouring on smaller parts with FANUC control and rapid traverse up to 945 IPM.
| Machine Type | CNC Vertical Machining Center |
|---|---|
| X-Axis Travel | 20.08" |
| Y-Axis Travel | 16.14" |
| Z-Axis Travel | 18.11" |
| Spindle Speed Range | 100–8,000 RPM |
| Spindle Power | 10 HP (7.5 HP continuous) |
| Spindle Taper | CAT 40 |
| Spindle Nose to Table | 5.31"–23.43" |
| Table Size | 27.56" × 17.13" |
| Tool Changer | 18-station side-mount twin-arm ATC |
| Max Tool Length | 9.65" |
| Max Tool Weight | 13.2 lbs |
| Max Cutting Feed Rate | 0.004–157 IPM |
| Rapid Traverse (X/Y/Z) | 945 / 945 / 787 IPM |
| CNC Control | FANUC 21-M |
| Machine Weight | ~7,700 lbs |
| Machine Dimensions | 77"L × 90"W × 110"H |
CNC Knee Milling
3 Machines
Bridgeport w/ ProtoTrak (×3)
Three Bridgeport-platform CNC knee mills with conversational ProtoTRAK controls. Two EMX and one Edge. Fast, intuitive setup without G-code makes these the go-to machines for prototype and short-run milling.
| Machine Type | CNC Knee Mill (Bridgeport Series 1 platform) |
|---|---|
| Table Size | 9" × 42"–48" |
| X-Axis Travel (Longitudinal) | 16"–33.5" (varies by model) |
| Y-Axis Travel (Cross) | 9"–12" |
| Z-Axis (Knee Vertical) | Up to 16" |
| Quill Travel | 5" |
| Ram Travel | 12" |
| Spindle Speed | 60–4,200 RPM (variable speed) |
| Spindle Motor | 2–3 HP |
| CNC Controls | ProtoTRAK EMX (2 machines) / ProtoTRAK Edge (1 machine) |
| Control Type | 2-axis CNC (X and Y) with DRO on Z-axis; conversational programming |
| Quantity | 3 machines |
| Machine Weight | ~2,816 lbs each |
Portable CNC Milling
1 Machine
Southwestern Trak 2OP
Pallet-jack movable second-operations machine with conversational ProtoTRAK TMX control. Light-duty drilling, tapping, and milling on parts already roughed on a primary machine, positioned right at the cell for workflow efficiency.
| Machine Type | Portable CNC Vertical Machining Center (Second Operations) |
|---|---|
| X/Y Travel | 12" × 14" |
| Table Size | 18" × 15" |
| T-Slots | 4 slots, 63 mm pitch, 0.630" (16 mm) width |
| Max Table Load | 500 lbs |
| Spindle Power | 4.5 HP max |
| Spindle Taper | 30-taper |
| CNC Control | ProtoTRAK TMX (conversational) |
| Standard Features | Contained work envelope, flood coolant, rigid tapping, pallet jack movable |
| Machine Dimensions | 30.5"W × 52"D × 92"–101"H |
| Portability | Designed to move via pallet jack; fits through standard doorways at 92" height |
Sawing
1 Machine
Amada H250 Cutting Saw
Precision raw material preparation with variable blade speed, auto-indexing up to 9 passes, and split/zero-clamp vise. Handles a wide range of bar stock, round, and rectangular materials to tight length tolerances before machining.
| Machine Type | Horizontal Band Saw |
|---|---|
| Round Cutting Capacity | 9.8" (250 mm) |
| Rectangular Cutting Capacity | 18" (H × W) |
| Blade Drive Motor | 5 HP |
| Blade Width | 1-1/4" |
| Blade Speed | 88–295 FPM (variable) |
| Blade Dimensions | 1-1/4" × 138" |
| Auto-Indexing | Up to 9 index passes (max cut length 141.7") |
| Frame Construction | Rigid C-section frame |
| Standard Features | Piece counter, diagnostic lights, pressure flow valve, kerf compensating dial, motion detector, split vise, zero-clamp vise, variable blade speed drive |
